1. Setting Mopria Print Service

1. Connect this machine to the same network as the mobile device.
   Connect this machine and the mobile device via a wireless LAN access point or directly with wireless LAN (AP mode).
   Connect this machine and the access point via wireless LAN (infrastructure) or wired LAN.
   To connect via wireless LAN (Infrastructure), please set it in advance.

   Connection form via a wireless LAN

   Connecting via an access point (Infrastructure)



   When connecting via a wired LAN, connect this machine to the access point with a LAN cable.



   To connect via a wireless LAN (AP mode), please set the wireless LAN (AP mode) in advance.

   Connection form via a wireless LAN

   Connecting directly with this machine (AP mode)



2. To use from a Windows, connect this machine to the Windows.
3. To print using the Mopria Print Service, configure the settings from the mobile device.

Go to "3. Printing with Mopria Print Service".
