If the Error Code is "409"

  1. Close the faceup stacker.

  2. Open the scanner unit.

  3. Press the top cover open button.

  4. Open the top cover.

  5. Remove the jammed paper.

  6. Close the top cover.

  7. Close the scanner unit.

  8. If paper jam error message is displayed, check it and remove jammed paper.
